300V Câbles CSA plats en cuivre solide Nmd90 12/3 Nmd90 Fil

300V Câbles CSA plats en cuivre solide Nmd90 12/3 Nmd90 Fil image

Get Latest Price Request a quote

Product Details

N° de Modèle.

NMD90

Demande

Chauffage , bâtiment

Matériau conducteur

Cuivre

Matériau de la gaine

PVC

Matériau isolant

PVC

Forme Matériel

Fil plat

Domaine d′application

conduits ou chemins de câbles reconnus pour les services

Certificat

ISO9001, CE, CCC, RoHS, VDE

Marque

huatong

tension

300V

utilisation

bâtiment

certificat

cul et csa

package

fûts en plastique et en bois

Paquet de Transport

bobines et tambours

Spécifications

14 awg, 12 awg, 10 awg, 8 awg, 6 awg

Marque Déposée

câbles ht

Origine

Chine

Code SH

8544492100

Capacité de Production

200000m/mois

Product Description

The largest CUL UL cable expert manufacturer in China

First factory in NMD90, TECK90, RPV90 mass production factory

Annual Export amount more than $500million, Yearly manufacturing capacity 5 Billion RMB.

Cable solutions to your particular requirements
Strict quality control system.
Strong technical support (technical data, drawing, etc.)
Free sample is available with economic express fee.

A P P L I C A T I O N S

NMD90 cables may be used for both exposed work in dry locations or concealed work in dry or damp locations.

The maximum allowable conductor temperature is 90°C. The minimum recommended installation temperature is -25°C for two-conductor cables and -10°C for three-conductor cables (with suitable handling procedures). Material should be properly stored above 0°C for 24 hours prior to installation. The maximum voltage rating for all intended applications is 300 volts. Consult the Canadian Electrical Code1 for further

information related to applications.

CONSTRUCTION

Canada standard C22.2 No. 48 (non-metallic sheathed cable)

Canadian Electrical Code1

NMD90 cables are available as two- or three-conductor cables with a bare grounding conductor. It is

manufactured using annealed (soft) copper conductors-compressed standing for stranded conductors; a

heat-resistant thermoplastic polyvinyl chloride (PVC) insulation and nylon jacket for the individual conductors with a PVC jacket for the overall construction.

SPECIFICATION

Conductor			Insulation		Ground		Approx. Jacket thickness		Approx. Cable Dia.		Approx. Cable weight		Allowable Ampacities 30°C
Size (AWG)	Cores	Strands	Inches	mm	Size (AWG)	Core	Inches	mm	Inches	mm	Ib/ 1000ft	Kg/ km
14	2	1	0.034	0.86	14	1	0.030	0.76	0.388*0.192	9.86*4.88	68	101	25*
14	2	1	0.034	0.86	14	1	0.030	0.76	0.388 x 0.192	9.86 x 4.88	68	101	25*
12	2	1	0.034	0.86	14	1	0.030	0.76	0.422 x 0.209	10.71 x 5.30	86	129	30*
10	2	1	0.034	0.86	12	1	0.030	0.76	0.481 x 0.230	12.21 x 5.84	122	182	40*
8	2	7	0.040	1.02	10	1	0.045	1.14	0.636 x 0.312	16.15 x 7.92	208	310	55
6	2	7	0.051	1.30	8	7	0.045	1.14	0.792 x 0.370	20.12 x 9.40	315	468	75
14	3	1	0.034	0.86	14	1	0.030	0.76	0.345	8.77	86	128	25*
12	3	1	0.034	0.86	14	1	0.030	0.76	0.381	9.69	114	169	30*
10	3	1	0.034	0.86	12	1	0.030	0.76	0.427	10.85	163	242	40*
8	3	7	0.040	1.02	10	1	0.045	1.14	0.570	14.47	275	408	55
6	3	7	0.051	1.30	8	7	0.045	1.14	0.695	17.65	421	627	75
3	3	7	0.051	1.30	6	7	0.080	2.03	0.925	23.48	799	1189	115

Qui nous sommes Chine 300V Câbles CSA plats en cuivre solide Nmd90 12/3 Nmd90 Fil fabrication et fournisseur,Vous pouvez obtenir plus de détails par e-mail, vous obtiendrez un prix bon marché ou un prix usine.
